Cisco Catalyst 2950 Hardware Installation Guide

CHAPTER
4-1
Catalyst 2950 Desktop Switch Hardware Installation Guide
78-11157-05
4
Troubleshooting
The front-panel LEDs provide troubleshooting information about the switch.
They show power-on self-test (POST) failures, port-connectivity problems, and
overall switch performance. For a full description of the LEDs, see the “LEDs”
section on page 2-17.
You can also get statistics from the Cluster Management Suite (CMS), the
command-line interface (CLI), the Cisco Intelligence Engine 2100 (IE2100)
Series Configuration Registrar, or a Simple Network Management Protocol
(SNMP) workstation. Refer to the switch software configuration guide, the switch
command reference, or the documentation that came with your IE2100 or SNMP
application for details.
This chapter provides these topics for troubleshooting problems:
• Understanding POST Results, page 4-2
• Diagnosing Problems, page 4-2

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
