Cisco Catalyst 2950 Hardware Installation Guide

v
Catalyst 2950 Desktop Switch Hardware Installation Guide
78-11157-05
CONTENTS
Cisco Limited Lifetime Hardware Warranty Terms xi
Preface xv
Audience xv
Purpose xv
Conventions xvi
Related Publications xxiii
Obtaining Documentation xxv
Cisco.com xxv
Documentation CD-ROM xxvi
Ordering Documentation xxvi
Documentation Feedback xxvi
Obtaining Technical Assistance xxvii
Cisco.com xxvii
Technical Assistance Center xxviii
Cisco TAC Website xxviii
Cisco TAC Escalation Center xxix
Obtaining Additional Publications and Information xxix
CHAPTER 1 Quick Installation 1-1
Taking Out What You Need 1-2
Connecting to the Console Port 1-3
Starting the Terminal Emulation Software 1-4
Connecting to a Power Source 1-5

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
