Cisco Catalyst 2950 Hardware Installation Guide

2-27
Catalyst 2950 Desktop Switch Hardware Installation Guide
78-11157-05
Chapter 2 Overview
Rear-Panel Description
Figure 2-22 Bandwidth Utilization on Catalyst 2950G-48-EI Switches
Rear-Panel Description
Other than the Catalyst 2950G-24-EI-DC switch and the Catalyst 2950 LRE
switches, the rear panel of a Catalyst 2950 switch has an AC power connector, an
RPS connector, and an RJ-45 console port. (See Figure 2-23 and Figure 2-24.)
The rear panel of the Catalyst 2950G-24-EI-DC switch has a DC power connector
(also referred to as the terminal block header), a DC ground lug, an RPS
connector, and an RJ-45 console port. (See Figure 2-25.)
The rear panel of the Catalyst 2950ST-8 LRE, 2950ST-24 LRE, and 2950ST-24
LRE 997 switches has only an RPS connector. (See Figure 2-26.)
Figure 2-23 Catalyst 2950 Switch Rear Panel
65510
2
Catalyst 2950
1
< 25% +
1
1X
2X
15X
16X
2 3 24 5 6 7 8 9 10 11 12 13 14 15 16 17
17X
18X
31X
32X
18 19 20 21 22 23 24 25 26 27 28 29 31 31 32 33
33X
34X
47X
48X
34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
50% +
25% – 49% +
SYST
RPS
STAT
UTIL
DUPLX
SPEED
MODE
R
ATING
100-127V~
@
1A
200-240V~
@
0.5A
50-60Hz
D
C INPUT FO
R RE
MO
TE
PO
W
ER SU
PPLY
S
PECIFIED IN
M
AN
UAL.
+12V @
4.5A
CON
SOLE
AC power
connector
RPS
connector
Fan
RJ-45
console port
45585

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
