Cisco Catalyst 2950 Hardware Installation Guide

CHAPTER
2-1
Catalyst 2950 Desktop Switch Hardware Installation Guide
78-11157-05
2
Overview
This chapter provides information about these topics:
• Features, page 2-1
• Front-Panel Description, page 2-4
• Rear-Panel Description, page 2-27
• Management Options, page 2-32
Features
The Catalyst 2950 switches are a family of Ethernet switches that you can use to
connect workstations and other network devices, such as servers, routers, and
other switches. All models of the switch are cluster-capable, but only some
models are stackable. You can use switches with Gigabit Interface Converter
(GBIC) module slots to create switch stacks by using Gigastack GBICs. Some
switch models can be deployed as backbone switches, aggregating 10BASE-T,
100BASE-TX, Gigabit Ethernet, and Long-Reach Ethernet (LRE) traffic from
other switches and network devices. Refer to the switch software configuration
guide for examples that show how you might deploy the switches in your network.

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
