Front-Panel Description
2-4
Catalyst 2950 Desktop Switch Hardware Installation Guide
78-11157-05
Certain Cisco LRE customer premises equipment (CPE) devices are not supported
by certain Catalyst 2950 LRE switches. In Table 2-1, Yes means that the CPE is
supported by the switch; No means that the CPE is not supported by the switch.
Front-Panel Description
The switch front panel contains the ports, the LEDs, and the Mode button.
Other than the Catalyst 2950ST-24 LRE 997 switch, the front panel of the
Catalyst 2950 LRE switches also contains the console port and AC power
connector. On the Catalyst 2950ST-24 LRE 997 switch, the front panel contains a
DC power connector (also referred to as the terminal block header), a DC ground
lug, and an RJ-45 console port.
For more information about the power connectors on the LRE switches, see the
“Power Connectors” section on page 2-29. For more information on the console
port on these switches, see the “Console Port” section on page 2-31.
Table 2-1 LRE Switch and CPE Compatibility Matrix
LRE Devices
Catalyst 2950ST-8 LRE
switch
Catalyst 2950ST-24 LRE
switch
Catalyst 2950ST-24 LRE 997
switch
Cisco 575 LRE
CPE
Yes Yes No
Cisco 576 LRE 997
CPE
No No Yes
Cisco 585 LRE
CPE
Yes Yes No

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
