Cisco Catalyst 2950 Hardware Installation Guide

3-45
Catalyst 2950 Desktop Switch Hardware Installation Guide
78-11157-05
Chapter 3 Installation
Connecting to GBIC Module Ports
When connecting the ports on the Catalyst 2950G-24-EI-DC and
Catalyst 2950ST-24 LRE 997 switches to other devices, follow these guidelines:
Caution To comply with the intrabuilding lightning surge requirements, intrabuilding
wiring must be shielded, and the shield for the wiring must be grounded at both
ends.
Caution The Catalyst 2950G-24-EI-DC or Catalyst 2950ST-24 LRE 997 switch is suitable
only for intrabuilding or nonexposed wiring connections.
Connecting to 1000BASE-X GBIC Module Ports
Caution Do not remove the rubber plugs from the GBIC module port or the rubber caps
from the fiber-optic cable until you are ready to connect the cable. The plugs and
caps protect the GBIC module ports and cables from contamination and ambient
light.
After installing the 1000BASE-X GBIC in the GBIC module slot, follow these
steps:
Step 1 Remove the rubber plugs from the GBIC module port, and store them for future
use.
Step 2 Insert the SC connector in the fiber-optic receptacle (see Figure 3-38).

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
