Cisco Catalyst 2950 Hardware Installation Guide

B-1
Catalyst 2950 Desktop Switch Hardware Installation Guide
78-11157-05
APPENDIX
B
Connectors and Cables
This appendix describes the connectors, cables, and adapters that you use to
connect the switch to other devices.
Connector Specifications
These sections describe the connectors used with the Catalyst 2950 switches and
contains this information:
• 10/100 Ports, page B-2
• 10/100/1000 Ports, page B-3
• 100BASE-FX and 1000BASE-SX Ports, page B-6
• LRE Port, page B-5
• GigaStack GBIC Module Ports, page B-7
• SFP Module Ports, page B-7
• Console Port, page B-8

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
