Chapter 1 Quick Installation
Taking Out What You Need
1-2
Catalyst 2950 Desktop Switch Hardware Installation Guide
78-11157-05
Taking Out What You Need
Remove the items shown in Figure 1-1 from the shipping container:
Figure 1-1 Catalyst 2950 Switch, Adapter Cable, and AC Power Cord
Note You need to provide the Category 5 straight-through cables to connect the switch
ports to other Ethernet devices.
1 Catalyst 2950 switch
2 RJ-45-to-DB-9 adapter cable
3 AC power cord
