PurposeCommand or Action
•
Create an access list that specifies the range of multicast groups from
which to accept or deny (group-list ACL).
•
For source, enter the multicast group address range for which the RP
should be used.
•
(Optional) For source-wildcard, enter the wildcard bits in dotted decimal
notation to be applied to the source. Place ones in the bit positions that
you want to ignore.
The access list is always terminated by an implicit deny statement for
everything.
Returns to privileged EXEC mode.end
Example:
Device(config)# end
Step 5
Verifies your entries.show running-config
Example:
Device# show running-config
Step 6
(Optional) Saves your entries in the configuration file.copy running-config startup-config
Example:
Device# copy running-config
Step 7
startup-config
Related Topics
Example: Filtering Incoming RP Announcement Messages, on page 183
Configuring PIMv2 BSR
The process for configuring PIMv2 BSR may involve the following optional tasks:
•
Defining the PIM domain border
•
Defining the IP multicast boundary
•
Configuring candidate BSRs
•
Configuring candidate RPs
IP Multicast Routing Configuration Guide, Cisco IOS XE Release 3.6E (Catalyst 3850 Switches)
154 OL-32598-01
Configuring PIM
Configuring PIMv2 BSR

Cisco Catalyst 3850 series Specifications

General

Model	Cisco Catalyst 3850 Series
RAM	4 GB
Flash Memory	4 GB
Stacking Bandwidth	480 Gbps
Device Type	Switch
Enclosure Type	Rack-mountable
Routing Protocol	OSPF, EIGRP, BGP, RIP
Remote Management Protocol	SNMP, CLI, HTTP, HTTPS
Features	Quality of Service (QoS)
Stacking	Yes
Memory	4 GB RAM
Operating System	Cisco IOS
Relative Humidity	10 - 95% (non-condensing)
Power Supply Options	AC or DC
Ports	24 or 48 10/100/1000 Ethernet ports
