Page #298 background image
Before You Begin
This task does not include the steps for configuring DNS-based SSM mapping. See the Configuring DNS-Based
SSM Mapping(CLI), on page 271 task for more information about configuring DNS-based SSM mapping.
SUMMARY STEPS
1.
enable
2.
configure terminal
3.
interface type number
4.
ip igmp static-group group-address source ssm-map
DETAILED STEPS
PurposeCommand or Action
Enables privileged EXEC mode.enable
Step 1
Example:
Router> enable
•
Enter your password if prompted.
Enters global configuration mode.configure terminal
Example:
Router# configure terminal
Step 2
Selects an interface on which to statically forward traffic for a multicast
group using SSM mapping and enters interface configuration mode.
interface type number
Example:
Router(config)# interface
gigabitethernet 1/0/0
Step 3
Static forwarding of traffic with SSM mapping works with
either DNS-based SSM mapping or statically-configured SSM
mapping.
Note
Configures SSM mapping to be used to statically forward a (S, G)
channel out of the interface.
ip igmp static-group group-address source
ssm-map
Step 4
Example:
Router(config-if)# ip igmp static-group
232.1.2.1 source ssm-map
•
Use this command if you want to statically forward SSM traffic
for certain groups, but you want to use DNS-based SSM mapping
to determine the source addresses of the channels.
Configuring Static Traffic Forwarding with SSM Mapping (CLI)
Follow these steps to configure static traffic forwarding with SSM mapping on the last hop router:
IP Multicast Routing Configuration Guide, Cisco IOS XE Release 3.6E (Catalyst 3850 Switches)
274 OL-32598-01
Configuring SSM
Configuring SSM Mapping
