Troubleshooting
Cisco RVS4000 Security Router with VPN Administrator Guide 122
A
STEP 4 Configure as many entries as you like.
STEP 5 When you have completed the configuration, click Save.
I need to set up online game hosting or use other Internet applications.
If you want to play online games or use Internet applications, most will work
without doing any port forwarding or DMZ hosting. There may be cases when you
want to host an online game or Internet application. In this situation, you need to set
up the router to deliver incoming packets or data to a specific computer. This also
applies to the Internet applications you are using. The best way to get the
information on what port services to use is to go to the website of the online game
or application you want to use. Follow these steps to set up online game hosting or
use a certain Internet application:
STEP 1 Access the router’s configuration utility by going to http://192.168.1.1 or the IP
address of the router. Go to Firewall > Single Port Forwarding.
STEP 2 Select the Service from the Application column.
STEP 3 Enter the IP Address of the server that you want the Internet users to access. For
example, if the web server’s Ethernet adapter IP address is 192.168.1.100, you
would enter 100 in the field provided. Then check the Enable box for the entry.
Consider the examples below:
STEP 4 Configure as many entries as you like.
STEP 5 When you have completed the configuration, click Save.
Application Start and End Protocol IP Address Enable
UT 7777 to 27900 Both 192.168.1.100 X
Halflife 27015 to 27015 Both 192.168.1.105 X
PC Anywhere 5631 to 5631 UDP 192.168.1.102 X
VPN IPSEC 500 to 500 UDP 192.168.1.100 X
