Setting Up and Configuring the Router
Firewall
Cisco RVS4000 Security Router with VPN Administrator Guide 55
5
Enabled Click the Enabled checkbooks to enable port forwarding for the relevant
application.
Click Save to save your changes, or click Cancel to undo your changes.
Firewall > Port Range Forwarding
Firewall > Port Range Forwarding
Application Enter the name of the application you wish to configure.
Start The beginning of the port range. Enter the beginning of the range of port
numbers (external ports) used by the server or Internet application. Check with the
software documentation of the Internet application for more information if
necessary.
End The end of the port range. Enter the end of the range of port numbers
(external ports) used by the server or Internet application. Check with the software
documentation of the Internet application for more information if necessary.
Protocol Select the protocol(s) used for this application, TCP and/or UDP.
IP Address For each application, enter the IP address of the PC running the
specific application.
Enabled Click the Enabled checkbooks to enable port range forwarding for the
relevant application.
Click Save to save your changes, or click Cancel to undo your changes.

Cisco RVS4000 - Gigabit Security Router Specifications

General

WAN Ports	1 x 10/100/1000 Mbps
LAN Ports	4 x 10/100/1000 Mbps
VPN Support	IPSec, PPTP
Wireless	No
QoS	Yes
Power Supply	12V DC, 1.5A
Humidity	10% to 85% non-condensing
Firewall	SPI Firewall
VPN Throughput	30 Mbps
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-4°F to 158°F (-20°C to 70°C)
Management	Web-based
