4-6
Cisco SCE8000 GBE Installation and Configuration Guide
OL-19897-02
Chapter 4 Installing the Cisco SCE8000 GBE Chassis
Preparing for Installation
Table 4-4 lists the AC-input power cord options, specifications, and Cisco product numbers for the 2700
W AC-input power supplies. Table 4-4 also references power cord illustrations.
AC-fusing requirements For North America, the circuit breaker should be rated at
20A.
For everywhere else, the circuit breaker should be sized
according to the input current rating and local or national
code requirements.
AC-input frequency rating 50/60 Hz (nominal) (±3% for full range)
Table 4-3 Cisco SCE 8000 GBE AC Power Specifications (continued)
Specification Acceptable Range
Table 4-4 AC-Input Power Cord Options
Locale Part Number Length Plug Rating
Power Cord
Reference
Illustration
North America
(locking)
CAB-GSR16-US(
=)
14 feet (4.3m) 250VAC, 20A Figure 4-1
Europe CAB-GSR16-EU(
=)
14 feet (4.3m) 250VAC, 16A Figure 4-1
International CAB-AC16A-90L
-IN(=)
14 feet (4.3m) 250VAC, 16A Figure 4-1
China CAB-AC16A-CH
=
14 feet (4.3 m) 250VAC, 16A Figure 4-2
Continental
Europe
CAB-AC-2500W-
EU=
14 feet (4.3 m) 250VAC, 16A Figure 4-3
International CAB-AC-2500W-I
NT=
14 feet (4.3 m) 250VAC, 16A Figure 4-4
Israel CAB-AC-2500W-I
SRL=
14 feet (4.3 m) 250VAC, 16A Figure 4-5
Japan, North
America
(nonlocking plug)
200–240VAC
operation
CAB-AC-2500W-
US1=
14 feet (4.3 m) 250VAC, 16A Figure 4-6
Japan, North
America (locking
plug)
200–240VAC
operation
CAB-AC-C6K-T
WLK=
14 feet (4.3 m) 250VAC, 16A Figure 4-7
Japan, North
America
100–120VAC
operation1
CAB-7513AC= 14 feet (4.3 m) 125VAC, 20A Figure 4-8
South Africa CAB-7513ACSA= 14 feet (4.3 m) 250VAC, 16A Figure 4-9
