Cisco Small Business 200 Series Administration Guide

Administration: Discovery
Configuring LLDP
Cisco Small Business 200 Series Smart Switch Administration Guide 101
9
VLAN IDs
VLAN ID Table
• VID—Port and Protocol VLAN ID.
• VLAN Name—Advertised VLAN names.
Protocol IDs
• Protocol ID—Advertised protocol IDs.
Location Information
Enter the following data structures in hexadecimal as described in section 10.2.4 of the ANSI-TIA-1057
standard:
• Civic—Civic or street address.
• Coordinates—Location map coordinates—latitude, longitude, and altitude.
• ECS ELIN—Device’s Emergency Call Service (ECS) Emergency Location Identification Number (ELIN).
• Unknown—Unknown location information.
Network Policies
Network Policy Table
• Application Type—Network policy application type, for example, Voice.
• VLAN ID—VLAN ID for which the network policy is defined.
• VLAN Type—VLAN type, Tagged or Untagged, for which the network policy is defined.
• User Priority—Network policy user priority.
• DSCP—Network policy DSCP.
STEP 4 Select a port and click LLDP Port Status Table to see the details in the LLDP Port
Status Table.
LLDP Statistics
The LLDP Statistics page displays LLDP statistical information per port.
To view the LLDP statistics:
