Cisco Small Business 200 Series Administration Guide

Status and Statistics
802.1X EAP Statistics
Cisco Small Business 200 Series Smart Switch Administration Guide 20
3
STEP 1 Click Status and Statistics > Etherlike.
STEP 2 Enter the parameters.
• Interface—Select the type of interface and specific interface for which Ethernet statistics are to be
displayed.
• Refresh Rate—Select the amount of time that passes before the Etherlike statistics are refreshed.
The fields are displayed for the selected interface.
• Frame Check Sequence (FCS) Errors—Received frames that failed the CRC (cyclic redundancy
checks).
• Single Collision Frames—Frames that were involved in a single collision, but were successfully
transmitted.
• Late Collisions—Collisions that have been detected after the first 512 bits of data.
• Excessive Collisions—Transmissions rejected due to excessive collisions.
• Oversize Packets—Packets greater than 2000 octets received.
• Internal MAC Receive Errors—Frames rejected because of receiver errors.
• Pause Frames Received—Received flow control pause frames.
• Pause Frames Transmitted—Flow control pause frames transmitted from the selected interface.
To clear statistics counters:
• Click Clear Interface Counters to clear the selected interfaces counters.
• Click View All Interfaces Statistics to see all ports on a single page.
802.1X EAP Statistics
The 802.1x EAP page displays detailed information regarding the EAP (Extensible Authentication Protocol)
frames that were sent or received. To configure the 802.1X feature, see the 802.1X Properties page.
To view the EAP Statistics and/or set the refresh rate:
STEP 1 Click Status and Statistics > 802.1x EAP.
STEP 2 Select the Interface that is polled for statistics.
