Cisco Small Business 200 Series

VLAN Management
Voice VLAN
Cisco Small Business 200 Series Smart Switch Administration Guide 192
14
Voice VLAN Configuration
This section describes how to configure voice VLAN. It covers the following topics:
• Configuring Voice VLAN Properties
• Auto Voice VLAN Settings
• Telephony OUI
Configuring Voice VLAN Properties
Use the Voice VLAN Properties page for the following:
• View how voice VLAN is currently configured.
• Configure the VLAN ID of the Voice VLAN.
• Configure voice VLAN QoS settings.
• Configure the voice VLAN mode (Telephony OUI or Auto Voice VLAN).
• Configure how Auto Voice VLAN is triggered.
To view and configure Voice VLAN properties:
STEP 1 Click VLAN Management > Voice VLAN > Properties.
• The voice VLAN settings configured on the device are displayed in the Voice VLAN Settings
(Administrative Status) block.
• The voice VLAN settings that are actually being applied to the voice VLAN deployment are displayed
in the Voice VLAN Settings (Operational Status) block.
STEP 2 Enter values for the following fields:
• Voice VLAN ID—Enter the VLAN that is to be the Voice VLAN.
NOTE Changes in the voice VLAN ID, CoS/802.1p, and/or DSCP cause the device to advertise the
administrative voice VLAN as a static voice VLAN. If the option
Auto Voice VLAN Activation triggered
by external Voice VLAN is selected, then the default values need to be maintained.
• CoS/802.1p —Select a CoS/802.1p value that to be used by LLDP-MED as a voice network policy.
Refer to
Administration > Discovery > LLDP > LLDP MED Network Policy for additional details.
• DSCP—Selection of DSCP values that to be used by the LLDP-MED as a voice network policy. Refer
to
Administration > Discovery > LLDP > LLDP MED Network Policy for additional details.
• Dynamic Voice VLAN—Select this field to disable or enable voice VLAN feature in one of the
following ways:
