Cisco Small Business 200 Series Administration Guide

SNMP
Configuring SNMP Views
Cisco Small Business 200 Series Smart Switch Administration Guide 324
24
- Link Local—The IPv6 address uniquely identifies hosts on a single network link. A link local
address has a prefix of FE80, is not routable, and can be used for communication only on the local
network. Only one link local address is supported. If a link local address exists on the interface, this
entry replaces the address in the configuration.
- Global—The IPv6 address is a global Unicast IPV6 type that is visible and reachable from other
networks.
• Link Local Interface—Select the link local interface (if IPv6 Address Type Link Local is selected) from
the list.
• Server IP Address/Name—Enter the IP address or domain name of the log server.
• Engine ID—Enter the Engine ID.
STEP 5 Click Apply. The Running Configuration file is updated.
Configuring SNMP Views
A view is a user-defined label for a collection of MIB subtrees. Each subtree ID is defined by the Object ID
(OID) of the root of the relevant subtrees. Either well-known names can be used to specify the root of the
desired subtree or an OID can be entered (see Model OIDs).
Each subtree is either included or excluded in the view being defined.
The Views page enables creating and editing SNMP views. The default views (Default, DefaultSuper)
cannot be changed.
Views can be attached to groups in the Groups page or to a community which employs basic access mode
through the Communities page.
To define SNMP views:
STEP 1 Click SNMP > Views.
STEP 2 Click Add to define new views.
STEP 3 Enter the parameters.
• View Name—Enter a view name between 0-30 characters)
• Object ID Subtree—Select the node in the MIB tree that is included or excluded in the selected SNMP
view. The options to select the object are as follows:
