Cisco Small Business 200 Series Administration Guide

Administration: Discovery
Configuring LLDP
Cisco Small Business 200 Series Smart Switch Administration Guide 92
9
LLDP MED Port Settings
The LLDP MED Port Settings page enables the selection of the LLDP-MED TLVs and/or the network policies
to be included in the outgoing LLDP advertisement for the desired interfaces. Network Policies are
configured using the LLDP MED Network Policy page.
NOTE If LLDP-MED Network Policy for Voice Application (LLDP-MED Network Policy
Page) is Auto and Auto Voice VLAN is in operation, then the device automatically
generates an LLDP-MED Network Policy for Voice Application for all the ports that
are LLDP-MED enabled and are members of the voice VLAN.
To configure LLDP MED on each port:
STEP 1 Click Administration > Discovery - LLDP > LLDP MED Port Settings.
This page displays the following LLDP MED settings for all ports (only fields not described in the Edit page
are listed):
• Location—Whether Location TLV is transmitted.
• PoE—Whether POE-PSE TLV is transmitted.
• Inventory—Whether Inventory TLV is transmitted.
STEP 2 The message at the top of the page indicates whether the generation of the LLDP
MED Network Policy for the voice application is automatic or not (see LLDP
Overview). Click on the link to change the mode.
STEP 3 To associate additional LLDP MED TLV and/or one or more user-defined LLDP
MED Network Policies to a port, select it, and click Edit.
STEP 4 Enter the parameters:
• Interface—Select the interface to configure.
• LLDP MED Status—Enable/disable LLDP MED on this port.
• SNMP Notification—Select whether SNMP notification is sent on a per-port basis when an end
station that supports MED is discovered; for example a SNMP managing system, when there is a
topology change.
• Selected Optional TLVs—Select the TLVs that can be published by the device by moving them from
the Available Optional TLVs list to the Selected Optional TLVs list.
• Available Network Policies—Select the LLDP MED policies to be published by LLDP by moving them
from the Available Network Policies list to the Selected Network Policies list. These were created in
the LLDP MED Network Policy page
. To include one or more user-defined network polices in the
advertisement, you must also select Network Policy from the Available Optional TLVs.
