Cisco Small Business 200 Series Administration Guide

Administration: Discovery
Configuring LLDP
Cisco Small Business 200 Series Smart Switch Administration Guide 94
9
• LLDP Status—LLDP publishing option.
• LLDP MED Status—Enabled or disabled.
• Local PoE—Local PoE information advertised.
• Remote PoE—PoE information advertised by the neighbor.
• # of neighbors—Number of neighbors discovered.
• Neighbor Capability of 1st Device—Displays the primary functions of the neighbor; for example:
Bridge or Router.
LLDP Local Information
To view the LLDP local port status advertised on a port:
STEP 1 Click Administration > Discovery - LLDP > LLDP Local Information.
STEP 2 Select the interface for which LLDP local information is to be displayed.
This page displays the following fields for the selected interface:
Global
• Chassis ID Subtype—Type of chassis ID. (For example, the MAC address.)
• Chassis ID—Identifier of chassis. Where the chassis ID subtype is a MAC address, the MAC address
of the device appears.
• System Name—Name of device.
• System Description—Description of the device (in alpha-numeric format).
• Supported System Capabilities—Primary functions of the device, such as Bridge, WLAN AP, or
Router.
• Enabled System Capabilities—Primary enabled function(s) of the device.
• Port ID Subtype—Type of the port identifier that is shown.
• Port ID—Identifier of port.
• Port Description—Information about the port, including manufacturer, product name and hardware/
software version.
