Cisco Small Business 200 Series Administration Guide

Administration: Discovery
Configuring LLDP
Cisco Small Business 200 Series Smart Switch Administration Guide 102
9
STEP 1 Click Administration > Discovery - LLDP > LLDP Statistics.
For each port, the fields are displayed:
• Interface—Identifier of interface.
• Tx Frames (Total)—Number of transmitted frames.
• Rx Frames
-
To t a l —Number of received frames.
-
Discarded —Total number of received frames that were discarded.
-
Errors —Total number of received frames with errors.
• Rx TLVs
-
Discarded —Total number of received TLVs that were discarded.
-
Unrecognized —Total number of received TLVs that were unrecognized.
• Neighbor's Information Deletion Count—Number of neighbor ageouts on the interface.
STEP 2 Click Refresh to view the latest statistics.
LLDP Overloading
LLDP adds information as LLDP and LLDP-MED TLVs into the LLDP packets. LLDP overload occurs when the
total amount of information to be included in a LLDP packet exceed the maximum PDU size supported by an
interface.
The LLDP Overloading page
displays the number of bytes of LLDP/LLDP-MED information, the number of
available bytes for additional LLDP information, and the overloading status of every interface.
To view LLDP overloading information:
STEP 1 Click Administration > Discovery - LLDP > LLDP Overloading.
This page contains the following fields for each port:
• Interface—Port identifier.
• Total Bytes In-Use—Total number of bytes of LLDP information in each packet
• Available Bytes Left—Total number of available bytes left for additional LLDP information in each
packet.
