Cisco Small Business 200 Series Administration Guide

Status and Statistics
Health
Cisco Small Business 200 Series Smart Switch Administration Guide 21
3
STEP 3 Select the Refresh Rate (time period) that passes before the EAP statistics are
refreshed.
The values are displayed for the selected interface.
• EAPOL Frames Received—Valid EAPOL frames received on the port.
• EAPOL Frames Transmitted—Valid EAPOL frames transmitted by the port.
• EAPOL Start Frames Received—EAPOL Start frames received on the port.
• EAPOL Logoff Frames Received—EAPOL Logoff frames received on the port.
• EAP Response/ID Frames Received—EAP Resp/ID frames received on the port.
• EAP Response Frames Received—EAP Response frames received by the port (other than Resp/ID
frames).
• EAP Request/ID Frames Transmitted—EAP Req/ID frames transmitted by the port.
• EAP Request Frames Transmitted—EAP Request frames transmitted by the port.
• Invalid EAPOL Frames Received—Unrecognized EAPOL frames received on this port.
• EAP Length Error Frames Received—EAPOL frames with an invalid Packet Body Length received on
this port.
• Last EAPOL Frame Version—Protocol version number attached to the most recently received
EAPOL frame.
• Last EAPOL Frame Source—Source MAC address attached to the most recently received EAPOL
frame.
To clear statistics counters:
• Click Clear Interface Counters to clear the selected interfaces counters.
• Click Refresh to refresh the selected interfaces counters.
• Click View All Interfaces Statistics to clear the counters of all interfaces.
Health
See Health.
