Administration: Discovery
Configuring LLDP
Cisco Small Business 200 Series Smart Switch Administration Guide 93
9
NOTE The following fields must be entered in hexadecimal characters in the exact data format that is
defined in the LLDP-MED standard (ANSI-TIA-1057_final_for_publication.pdf):
- Location Coordinate—Enter the coordinate location to be published by LLDP.
- Location Civic Address—Enter the civic address to be published by LLDP.
- Location ECS ELIN—Enter the Emergency Call Service (ECS) ELIN location to be published by
LLDP.
STEP 5 Click Apply. The LLDP MED port settings are written to the Running Configuration
file.
LLDP Port Status
The LLDP Port Status Table page contains the LLDP global information for every port.
STEP 1 To view the LLDP port status, click Administration > Discovery - LLDP > LLDP
Port Status.
STEP 2 Click LLDP Local Information Detail to see the details of the LLDP and LLDP-MED
TLVs sent to the neighbor.
STEP 3 Click LLDP Neighbor Information Detail to see the details of the LLDP and LLDP-
MED TLVs received from the neighbor.
LLDP Port Status Global Information
• Chassis ID Subtype—Type of chassis ID (for example, MAC address).
• Chassis ID—Identifier of chassis. Where the chassis ID subtype is a MAC address, the MAC address
of the device appears.
• System Name—Name of device.
• System Description—Description of the device (in alpha-numeric format).
• Supported System Capabilities—Primary functions of the device, such as Bridge, WLAN AP, or
Router.
• Enabled System Capabilities—Primary enabled function(s) of the device.
• Port ID Subtype—Type of the port identifier that is shown.
LLDP Port Status Table
• Interface—Port identifier.
