Cisco Small Business 200 Series Administration Guide

Port Management
Configuring Green Ethernet
Cisco Small Business 200 Series Smart Switch Administration Guide 133
10
- LLDP Administrative—Displays whether advertising EEE counters through LLDP was enabled.
- LLDP Operational—Displays whether advertising EEE counters through LLDP is currently
operating.
- EEE Support on Remote—Displays whether EEE is supported on the link partner. EEE must be
supported on both the local and remote link partners.
NOTE The window displays the Short Reach, Energy Detect and EEE settings for each port; however,
they are not enabled on any port unless they are also enabled globally by using the Properties page.
To enable Short Reach and EEE globally, see Global Green Ethernet Properties.
STEP 2 Select a Port and click Edit.
STEP 3 Select to enable or disable Energy Detect mode on the port.
STEP 4 Select to enable or disable Short Reach mode on the port if there are GE ports on
the device.
STEP 5 Select to enable or disable 802.3 Energy Efficient Ethernet (EEE) mode on the port
if there are GE ports on the device.
STEP 6 Select to enable or disable 802.3 Energy Efficient Ethernet (EEE) LLDP mode on
the port (advertisement of EEE capabilities through LLDP) if there are GE ports on
the device.
STEP 7 Click Apply. The Green Ethernet port settings are written to the Running
Configuration file.
