NGT—Checks and adjustments
150 NGT Transceiver System Technical Service Manual
Drawing 08-06260
Table 42: Supply voltages for the Application Processor Handset & Data
I/F PCB in the RF unit (2012 only)
Supply Description Source
+1V8 +1.8 V DSP core supply IC4
+3V3 +3.3 V switchmode supply IC5
+5 V +5 V regulated supply IC3
ALTERNATIVE TEXT
Drawing 08-05261 (sheet 1)
Table 43: Supply voltages for the RF/IF PCB in the RF unit (08-05261)
Supply Description Source
A Unregulated battery supply via Audio Interface PCB
+5 V +5 V regulated supply IC210
+26 V +26 V from charge pump
supply
IC402
+10 V +10 V regulated supply via Audio Interface PCB
+10 VRx +10 V In Rx V419, V420
+10 VTx +10 V In Tx V421, V422
