Codan NGT 2012 RF User Manual

08-05994-001
01 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
* Remote Control I/F, 8571
(NGT)
08-05994 1
1 Brkt, LHS Codan 08-04128-001 08-04128-001 1
2 Brkt, RHS Codan 08-04128-002 08-04128-002 1
3 Panel, LTU Mtg Metalcraft 08-04129 08-04129 1
4 Panel, Rear Codan 08-06032-001 08-06032-001 1
5 Panel, Front Metalcraft 05-06671-000 05-06671-000 1
6 Card Frame-Front Plate Metalcraft 08-04130 08-04130 1
7 Rail, Side Metalcraft 05-05210 05-05210 2
8 Cover, Top Metalcraft 05-07215 05-07215 1
9 Cover, Bottom Metalcraft 05-07216 05-07216 1
10 Label PMP 05-06514 05-06514 1
11 Plate, Blanking 15way D Metalcraft 05-05347 05-05347 1
12 Card Guide Metalcraft 06-01212 06-01212 3
13 Escutcheon, Front Entech 06-02123 06-02123 1
14 Backplane PCB Rapier Electronics 08-05995-001 08-05995-001 1
15 MicroP & Tcvr I/F PCB Rapier Electronics 08-03993 1
16 Dual Line Equaliser PCB Rapier Electronics 08-03905-002 08-03905-002 1
17 Opt RS PCB Rapier Electronics 08-04644-001 08-04644-001 1
18 Loom, Power Auto Assemblies 08-04157 08-04157 1
19 Cable, Ribbon,16way to 25way
D,F
Auto Assemblies 08-04158 08-04158 1
20 Plug Button (DP-625) Heyco 2663 (Black) 30-31110-006 3
21 Screw Lock assy, `D' 8,0mm
Stud
ITT-Cannon D20418-2 60-91509-001 2
22 Screw, M3x6 304 SS Bk Pan
Pozi
Spec 01-00205 31-23006-582 31-23006-582 8
23 Cable, Opt PS Auto Assemblies 08-03232 08-03232 1
24 Screw, M3x5 304 SS Csk Pozi RGA Fasteners 31-23005-780 31-23005-780 12
25 Screw, M3x8 304 SS Bk Csk
Pozi
Spec 01-00205 31-23008-782 31-23008-782 6
26 Screw,M3x10 304 SS Bk Csk
Pozi
Spec 01-00205 31-23010-782 31-23010-782 4
27 Nut, M3 MS Zn Pl Hex Spec 01-00201 31-23000-001 31-23000-001 3
28 Screw, 4Bx1/2 S/Tap Pan
Pozi
RGA Fasteners STD ZN PLATE 31-00408-902 12
29 Rivet, Pop Al Dome
2,4dx2,4mm
Tucker TAP/D/33/BS 33-23124-024 2
30 Screw, M4x8 MS Zn Pl CH
Slott ed
Spec 01-00201 31-24008-301 31-24008-301 1
31 Washer, M4 MS Zn Pl Bright
Normal
Spec 01-00201 31-24001-001 31-24001-001 1
32 Surround, Front moulded Cresta 06-01625 06-01625 1
33 Tape, Transfer 12mm 3M 969-12MMX16,4M ROLL 30-39308-004 40
34 Feet, Rubber Self Adhesive
15,7mm
Richco RBS-15 black 30-11208-000 4
35 Line Isolation Unit Single Chl Codan 08-03816-001 08-03816-001 1
36 Screw,M3x12 304 SS Bk Pan
Pozi
Spec 01-00205 31-23012-582 31-23012-582 2
08-05994-001 - Remote Control I/F, 8571 (NGT)
BOM Revision
Date Valid On
Page 1 of 1
