Codan NGT 2012 RF User Manual

08-05860-001
04 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
DSP Modem 3012PCB 08-05860 1
DSP Modem 3012 04-03366 1
Build Standard, 3012 01-01248 1
1 PCB, DSP Modem, 3012 IMP C119-656 07-01945-06 1
2 Label, Serial/Barcode Codan 06-02068 06-02068 1
3 Socket, 44PLCC IC, Surface
mount
Methode 213-044-602 60-00443-610 2
C101 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C102 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C103 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C105 22p 5% 50V NPO 0805
NiSn
Philips 0805CG220J9B200 46-12200-081 1
C106 22p 5% 50V NPO 0805
NiSn
Philips 0805CG220J9B200 46-12200-081 1
C107 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C108 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C109 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C110 10n 10% 100V X7R 0805
NiSn
Philips 08052R103K0B200 46-41000-281 1
C111 100u 20% 16V 7343H TA
Cap Low ESR
AVX TPSE107M016R0100 47-21001-600 1
C112 100u 20% 16V 7343H TA
Cap Low ESR
AVX TPSE107M016R0100 47-21001-600 1
C113 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C114 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C115 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C116 33u 20% 16V 7343 TA
Cap
AVX TAJD336M016R 47-13301-600 1
C117 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C118 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C119 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C120 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C121 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C122 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C123 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C124 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C125 470n 10% 16V X7R 1206
NiSn
AVX 1206YC474KAT1A 46-54700-282 1
C126 22u 20% 16V 5846 TA
Cap
NEC NRT226M16R 47-12201-620 1
08-05860-001 - DSP Modem PCB, 3012
BOM Revision
Date Valid On
Page 1 of 5
