Codan NGT 2012 RF User Manual

08-06461-001
03 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Heat, Transfer Compound Gensil GENSIL 13 45gm Tube 71-31000-004 0.01
TP, NGT FET Driver Bipolar
PA
10-01060 1
PA Filter & Control 04-03542 1
Spec, Test RD06HVF1 01-01698 1
PA c/w Heatsink PCB 08-06461 1
Assy Proc, NGT PA 11-06068 1
1 PCB, Power Amplifier Codan 07-02111-01 07-02111-01 1
2 Rivet, Tinned Brass Chobert
4,0dx9,5
Avdel 01143-00516 33-40340-095 2
3 Stake, Terminal Autosplice 7-22461-5 61-40300-004 8
4 Heatsink, RF Unit Diemetrics 05-07243 05-07243 1
5 Label, Serial/Barcode Codan 06-02068 06-02068 1
7 Cable, Ant control Intertech 08-05486-001 08-05486-001 1
8 Cable, PA O/P Coax COMOSS 08-05964-001 08-05964-001 1
9 Cable, Battery Cablex 08-05969-001 08-05969-001 1
11 Screw, M3x8 TAPTITE 2
P/Pozi
Ajax Fasteners 31-03008-580 31-03008-580 13
12 Lug, Solder 3,5mm Cliford W Ltd G410 CODE 330 61-30200-025 4
13 Washer, Mica (1kV) TO-220 Philips 56359B 30-45002-002 3
14 Bush, Transistor TO-220 Motorola B51547F019 30-03801-001 2
15 Tubing, Heatshrink 4,8x0,2
Bk
3M FP-301 3/16" Black 71-80502-400 0.01
17 Screw, M3x10 TAPTITE 2
P/Pozi
Ajax Fasteners 31-03010-582 31-03010-582 1
C200 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C201 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C202 100u 25V Ax EL Cap Elna RB 48-21002-551 1
C203 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C204 22p 5% 50V NPO 0805
NiSn
Philips 0805CG220J9B200 46-12200-081 1
C205 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C206 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C207 82p 5% 50V NPO 0805
NiSn
Philips 0805CG820J9B200 46-18200-081 1
C208 100u 25V Ax EL Cap Elna RB 48-21002-551 1
C209 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C210 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C211 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C212 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C213 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C214 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
08-06461-001 - PA c/w Heatsink PCB
BOM Revision
Date Valid On
Page 1 of 6
