Codan NGT 2012 RF User Manual

10 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05869-001 - PA Assy c/w Heatsink
BOM Revision
Date Valid On
T204 Output Transformer Protran 44-80277 44-80277 1
V200 Transistor, NPN Si 18V 0,15A
4GHz SOT89
Philips BFQ18A BFQ18A 1
V201 Transistor, NPN Si 18V 0,15A
4GHz SOT89
Philips BFQ18A BFQ18A 1
V202 JFET, N Channel SOT23 Philips PMBFJ309-215 PMBFJ309 1
V203 JFET, N Channel SOT23 Philips PMBFJ309-215 PMBFJ309 1
V204 Transistor, NPN Si 40V 100mA
1,2W SOT89
Philips PXT3904 PXT3904 1
V205 Transistor, NPN Si 40V 100mA
1,2W SOT89
Philips PXT3904 PXT3904 1
V206 Transistor, NPN Si SOT23 Philips BC847 BC847 1
V207 Transistor, NPN Si Mitsubishi 2SC1971 2SC1971 1
V208 Transistor, NPN Si Mitsubishi 2SC1971 2SC1971 1
V209 Transistor, NPN Si SOT23 Philips BC847 BC847 1
V210 Transistor, NPN Si SOT23 Philips BC847 BC847 1
V211 Transistor, RF Power HF Microsemi MS1253-CDN MS1253-CDN 1
V212 Transistor, RF Power HF Microsemi MS1253-CDN MS1253-CDN 1
V213 Transistor, Darlington NPN Si Philips BD675 BD675 1
V214 MOSFET, N Channel Enhance
SOT223
Philips BSP126 BSP126 1
V215 Transistor, PNP Si SOT23 Philips BC856 BC856 1
V216 Transistor, PNP Si SOT23 Philips BC856 BC856 1
V217 Transistor, PNP Si SOT89 Philips BC869 BC869 1
