Codan NGT 2012 RF User Manual

08-05890-001
03 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Switch, 2nd Filter 04-03379 1
2nd Filter PCB 08-05890 1
* 2nd Filter PCB 08-05890 1
1 PCB, 2nd Filter IMP 07-01962-02 07-01962-02 1
C1 27p 5% 50V NPO 0805
NiSn
Philips 0805CG270J9B200 46-12700-080 1
C2 27p 5% 50V NPO 0805
NiSn
Philips 0805CG270J9B200 46-12700-080 1
C3 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C4 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
D1 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
K1 Relay, 2C 12V 2A SMD 1028
Ohm
Matsushita TQ2SL-12V 64-21225-310 1
K2 Relay, 2C 12V 2A SMD 1028
Ohm
Matsushita TQ2SL-12V 64-21225-310 1
P1 Header (P) 4way 1row Molex 22-03-2041 60-00041-100 1
P2 Header (P) 4way 1row Molex 22-03-2041 60-00041-100 1
P3 Header (P) 2way 1row Molex 22-03-2021 60-00021-100 1
P4 Header (P) 2way 1row Molex 22-03-2021 60-00021-100 1
R1 1,8k Ohm 5% 0,1W 0805 Philips 2322 730 61182 40-31800-111 1
R2 3,3k Ohm 5% 0,1W 0805 Philips 2322 730 61332 40-33300-111 1
R3 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
Z1 Filter, 455 kHz 500 Hz BW Rockwell 526-8693-010 65-91118 1
08-05890-001 - 2nd Filter 500Hz PCB
BOM Revision
Date Valid On
Page 1 of 1
