High power—Overview and specifications
214 NGT Transceiver System Technical Service Manual
Pinouts of the DC supply connector on the power amplifier
The DC supply connector is on a flying lead from the rear of the power amplifier. There
are two DC supply connectors for the 1 kW power amplifier.
Figure 6: Front view of the DC supply connector on the power amplifier
Pinouts of the IEC mains connector (10 A) on the power supply
The IEC mains connector (10 A) is used in the power supply for the 500 W power
amplifier.
Figure 7: Front view of the IEC mains connector (10 A) on the power supply
Pinouts of the IEC mains connector (15 A) on the power supply
The IEC mains connector (15 A) is used in the power supply for the 1 kW power
amplifier.
Figure 8: Front view of the IEC mains connector (15 A) on the power supply
+70 V DC
Ground
NA
N A
