Codan NGT 2012 RF User Manual

08-05927-001
03 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
High Pwr ALC Adaptor 04-03407 1
TP, Hi Pwr SWR, ALC Adaptor 10-00891 1
High Pwr SWR, ALC Adaptor 08-05927 1
Assy Proc, High Pwr SWR,ALC
Adaptor
11-06065 1
1 Box, High Pwr SWR ALC
Adpator
Metalcraft 05-07242 05-07242 1
2 Escutcheon, Hi Pwr ALC
Adaptor
Entech 06-02098 06-02098 1
3 PCB, High Pwr ALC Adaptor IMP 07-01968-01 07-01968-01 1
4 Cable, ALC Auto Assemblies 08-05950-001 08-05950-001 1
5 Bush, Strain Relief Heyco 1017 (BLACK) 30-03802-003 1
6 Spacer, Threaded Hex
M3x8mm
PSM Fasteners SPA01-B-M3-8 30-37007-012 2
7 Screw, M3x5 304 SS Pan Pozi * 31-23005-580 31-23005-580 2
8 Screw, M3x6 304 SS Bl Csk
Pozi
Spec 01-00205 31-23006-782 31-23006-782 2
9 Screw, M3x6 TAPTITE 2
P/Pozi
Ajax Fasteners 304 Stainless 31-03006-580 8
10 Socket, UHF Flange Fixed Marushin MR-589 60-11360-589 2
11 Adaptor, UHF Plug to Plug Pasternack PE9096 60-11800 1
12 Sleeve, Helsyn H20x19 Any
Colour
Hellermann 2mmx0,75mmWallx19m
m
71-92007-199 1
13 Stake, Terminal Autosplice 7-22461-5 61-40300-004 2
14 Washer, M3x4,7OD 316S/S
Small
C D Brown KM48 31-23001-180 2
15 Washer, M3 304 SS Spring W.J.Smith 31-23001-580 31-23001-580 2
C1 3,3n 10% 100V X7R 1206
NiSn
Philips 12062R332K0BB- 46-33300-280 1
C2 3,3n 10% 100V X7R 1206
NiSn
Philips 12062R332K0BB- 46-33300-280 1
C3 10p 5% 500V NPO 1206
NiSn
Philips 1206CG100GBB- 46-11000-082 1
C4 10p 5% 500V NPO 1206
NiSn
Philips 1206CG100GBB- 46-11000-082 1
C5 10p 5% 500V NPO 1206
NiSn
Philips 1206CG100GBB- 46-11000-082 1
C6 5,5-65p 250V Foil Trim Cap Philips 2222 808 32659 49-30103 1
C7 390p 5% 500V NPO 1210
NiSn
Philips 1210CG391GBB- 46-23900-082 1
C8 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C9 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C10 4,7u 10% 16V 3528 TA
Cap
AVX TAJB475K016R 47-04701-600 1
C11 100p 5% 50V NPO 0805
NiSn
Philips 0805CG101J9B200 46-21000-081 1
C12 1n 10% 100V X7R 0805
NiSn
Philips 08052R102K0B200 46-31000-282 1
C13 47p 5% 500V NPO 1206
NiSn
Philips 1206CG470JDB2 46-14700-082 1
C14 Not Fitted Codan **-00000-001 99-00000-001 1
08-05927-001 - High Pwr SWR, ALC Adaptor
BOM Revision
Date Valid On
Page 1 of 2
