03 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05927-001 - High Pwr SWR, ALC Adaptor
BOM Revision
Date Valid On
D1 Diode, Schottky 70V 70mA
SOT23
Siemens BAS70 BAS70 1
D2 Diode, Schottky 70V 70mA
SOT23
Siemens BAS70 BAS70 1
D3 Diode, Schottky 40V 3A
SMC
Motorola MBRS340T3 MBRS340T3 1
IC1 Amp, Rail to Rail I/O
SOT23-5
National Semiconduct LMC7101BIM5X XA-07101-700 1
L1 Ind, 1mH 10% 1812 Coilcraft 1812LS-105XKBC 43-83100-000 1
L2 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
R1 27 Ohm 5% 0,33W CF
Res
Philips 2322 211 13279 40-12700-020 1
R2 27 Ohm 5% 0,33W CF
Res
Philips 2322 211 13279 40-12700-020 1
R3 27 Ohm 5% 0,33W CF
Res
Philips 2322 211 13279 40-12700-020 1
R4 27 Ohm 5% 0,33W CF
Res
Philips 2322 211 13279 40-12700-020 1
R5 39k Ohm 5% 0,1W 0805 Philips 2322 730 61393 40-43900-111 1
R6 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R7 100k Ohm 5% 0,1W 0805 Philips 2322 730 61104 40-51000-111 1
R8 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R9 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R10 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R11 3,3k Ohm 5% 0,1W 0805 Philips 2322 730 61332 40-33300-111 1
R12 6,8k Ohm 5% 0,1W 0805 Philips 2322 730 61682 40-36800-111 1
R14 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R15 Pot,10k Lin MG Trim Noble VTP 42-41076-000 1
R16 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R17 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R18 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
T1 Transformer, RF Current 30T Codan 44-80285 44-80285 1
V1 Transistor, NPN Si SOT23 Philips BC847 BC847 1
V2 Transistor, NPN Si SOT23 Philips BC847 BC847 1
V3 Transistor, NPN Si SOT23 Philips BC847 BC847 1
V4 Transistor, NPN Si SOT23 Philips BC817 BC817 1
Page 2 of 2
