Codan NGT 2012 RF User Manual

08-05987-001
06 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
HTS, 2011 DSP PCB 01-01235 1
Appn Proc, 3V (Handset I/F) 04-03424 1
Application Processor PCB, 3V 08-05987 1
1 PCB, Appn Proc3V (Handset
I/F)
IMP 07-01993-02 07-01993-02 1
2 Label, Identification/Barcode Codan 06-01852 06-01852 1
3 Cable, Ribbon, Audio - DSP Auto Assemblies 08-05490-001 08-05490-001 1
C1 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C2 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C3 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C4 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C5 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C6 10u 20% 20V 3528 TA
Cap
AVX TAJB106M020R 47-11002-000 1
C7 100n 10% 16V X7R 0603
NiSn
Vitramon VJ0603Y104KXJT 46-51000-283 1
C8 10u 20% 20V 3528 TA
Cap
AVX TAJB106M020R 47-11002-000 1
C9 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C10 100u 25V 105'C SMD EL
Cap Low ESR
Nippon Chemicn MVY25VC100MF80 48-21002-502 1
C11 100u 25V 105'C SMD EL
Cap Low ESR
Nippon Chemicn MVY25VC100MF80 48-21002-502 1
C12 10n 5% 50V X7R 0603
NiSn
Philips 06032R103J9BB00 46-41000-080 1
C13 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C14 100u 25V 105'C SMD EL
Cap Low ESR
Nippon Chemicn MVY25VC100MF80 48-21002-502 1
C15 10u 20% 20V 3528 TA
Cap
AVX TAJB106M020R 47-11002-000 1
C16 100n 10% 16V X7R 0603
NiSn
Vitramon VJ0603Y104KXJT 46-51000-283 1
C17 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C18 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C19 100n 10% 16V X7R 0603
NiSn
Vitramon VJ0603Y104KXJT 46-51000-283 1
C20 10u 20% 20V 3528 TA
Cap
AVX TAJB106M020R 47-11002-000 1
C21 100n 10% 16V X7R 0603
NiSn
Vitramon VJ0603Y104KXJT 46-51000-283 1
C22 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C23 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C24 1u 10% 16V X7R 1206
NiSn
Philips 12062R105K7BB00 46-61000-280 1
C25 3,3n 10% 100V X7R 0603
NiSn
Vishay VJ0603Y332KXBAC 46-33300-282 1
08-05987-001 - Appn Proc PCB,3V (Handset I/F)
BOM Revision
Date Valid On
Page 1 of 7
