Codan NGT 2012 RF User Manual

08-05415-001
03 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
PA PCB 08-05415 1
1 Spacer, Swaged Routley & W 05-05569 2
2 PCB, PA IMP 07-01799-03 07-01799-03 1
3 Stake, Terminal Autosplice 7-22461-5 61-40300-004 6
C200 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C201 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C202 100u 25V Ax EL Cap Elna RB 48-21002-551 1
C203 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C204 22p 5% 50V NPO 1206
NiSn
Philips 1206CG220J9BB- 46-12200-080 1
C205 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C206 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C207 15p 5% 500V NPO 1206
NiSn
Philips 1206CG150GBB- 46-11500-082 1
C208 100u 25V Ax EL Cap Elna RB 48-21002-551 1
C209 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C210 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C211 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C212 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C213 1n 5% 50V NPO 1206
NiSn
Philips 1206CG102J9BB- 46-31000-081 1
C214 100u 25V Ax EL Cap Elna RB 48-21002-551 1
C215 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C216 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C217 22p 5% 50V NPO 1206
NiSn
Philips 1206CG220J9BB- 46-12200-080 1
C218 22p 5% 50V NPO 1206
NiSn
Philips 1206CG220J9BB- 46-12200-080 1
C219 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
C220 10n 10% 100V X7R 1206
NiSn
Philips 12062R103K0BB- 46-41000-280 1
C221 10n 10% 100V X7R 1206
NiSn
Philips 12062R103K0BB- 46-41000-280 1
C222 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
C223 330p 5% 500V NPO 1210
NiSn
Philips 1210CG311GBB- 46-23300-082 1
C224 330p 5% 500V NPO 1210
NiSn
Philips 1210CG311GBB- 46-23300-082 1
C225 330p 5% 500V NPO 1210
NiSn
Philips 1210CG311GBB- 46-23300-082 1
C226 47p 5% 50V NPO 1206
NiSn
Philips 1206CG470J9BB- 46-14700-081 1
08-05415-001 - PA PCB
BOM Revision
Date Valid On
Page 1 of 5
