Codan NGT 2012 RF User Manual

08-05978-001
02 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
PSU 500/1000W Amp 04-03417 1
PSU 500/1000 W PA PCB 08-05978 1
TP,500W/1kW PSU Intermed
Build
10-00925 1
1 PCB, PSU 500/1000W PA IMP 07-01986-03 07-01986-03 1
2 Rivet, Tinned Brass Chobert
4,0dx9,5
Avdel 01143-00516 33-40340-095 4
3 Standoff, PCB 3,6x6 PEM KFE-3,6-6ET 33-53604-060 6
4 Stake, Terminal Autosplice 7-22461-5 61-40300-004 2
C1 2,2u 20% 20V 3528 TA
Cap
AVX TAJB225M020R 47-02202-000 1
C2 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C3 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C4 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C5 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C7 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C8 100u 25V 105'C SMD EL
Cap Low ESR
Nippon Chemicn MVY25VC100MF80 48-21002-502 1
C9 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C10 100n 10% 250V PE
Cap
BC Components 2222 370 41104 46-51000-522 1
C11 100n 10% 250V PE
Cap
BC Components 2222 370 41104 46-51000-522 1
C12 1000u 160V 105'C Ra EL
Cap Low ESR
Nippon Chemicn KMH160VNSN1000M25
E
48-31016-000 1
C13 1000u 160V 105'C Ra EL
Cap Low ESR
Nippon Chemicn KMH160VNSN1000M25
E
48-31016-000 1
C14 1000u 160V 105'C Ra EL
Cap Low ESR
Nippon Chemicn KMH160VNSN1000M25
E
48-31016-000 1
C15 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C16 100n 10% 100V X7R CE
Cap
Cinetech RD20B104K2AL5B 46-51000-263 1
C17 470n 10% 16V X7R 1206
NiSn
AVX 1206YC474KAT1A 46-54700-282 1
C18 330u 100V 105'C Ra EL
Cap Low ESR
Nippon Chemicn LXV100VB330ML30 48-23310-001 1
C19 330u 100V 105'C Ra EL
Cap Low ESR
Nippon Chemicn LXV100VB330ML30 48-23310-001 1
C20 330u 100V 105'C Ra EL
Cap Low ESR
Nippon Chemicn LXV100VB330ML30 48-23310-001 1
C21 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C22 470p 5% 50V NPO 0805
NiSn
Philips 0805CG471J9B200 46-24700-081 1
C23 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C24 100p 5% 500V NPO 1210
NiSn
Philips 1210CG101GBB- 46-21000-082 1
C25 100p 5% 50V NPO 0805
NiSn
Philips 0805CG101J9B200 46-21000-081 1
08-05978-001 - PSU 500/1000 W PA PCB
BOM Revision
Date Valid On
Page 1 of 7
