Codan NGT 2012 RF User Manual

08-06000-001
01 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
PCB, Combiner 4 way 1kW
Amp
Codan 07-01999-02 07-01999-02 1
Combiner 4 way 1kW Amp 04-03429 1
* Combiner 4 way PCB 1kW
Amp
08-06000 1
2 Tie, Cable 3,6mm W x 150mm
Long
Bowthorpe T30R 30-39101-001 2
3 Standoff, PCB 3,6x4 PEM KFE-3,6-4ET 33-53604-040 1
4 Standoff, PCB 3,6x6 PEM KFE-3,6-6ET 33-53604-060 3
5 Stake, Terminal Autosplice 7-22461-5 61-40300-004 6
C1 3,3n 10% 100V CE Cap Philips 2222 630 03332 46-33300-200 1
C2 22p 5% 500V NPO CE
Cap
Murata DD05 CH 220J 500 46-12200-020 1
C3 22p 5% 500V NPO CE
Cap
Murata DD05 CH 220J 500 46-12200-020 1
C4 33p 5% 500V NPO CE
Cap
Murata DD07 CH 330J 500 46-13300-020 1
D1 Diode, Schottky HV HP 5082-2800 5082-2800 1
D2 Diode, Schottky HV HP 5082-2800 5082-2800 1
D3 Diode, Schottky HV HP 5082-2800 5082-2800 1
J1 Socket, MCX Straight
PCB
Chin Nan 27-05-TGN 60-19300 1
J2 Socket, MCX Straight
PCB
Chin Nan 27-05-TGN 60-19300 1
J3 Socket, MCX Straight
PCB
Chin Nan 27-05-TGN 60-19300 1
J4 Socket, MCX Straight
PCB
Chin Nan 27-05-TGN 60-19300 1
R2 470 Ohm 5% 0,33W CF
Res
Philips 2322 211 13471 40-24700-020 1
R3 470 Ohm 5% 0,33W CF
Res
Philips 2322 211 13471 40-24700-020 1
R7 1,8k Ohm 5% 0,33W CF
Res
Philips 2322 211 13182 40-31800-020 1
R8 560 Ohm 5% 0,33W CF
Res
Philips 2322 211 13561 40-25600-020 1
T1 Txfr Output Combine 2 way 1,6
-
30MHz 500W
Protran 44-80299 44-80299 1
T2 Txfr Output Combine 2 way 1,6
-
30MHz 500W
Protran 44-80299 44-80299 1
T3 Txfr Output Combine 2 way 1,6
-
30MHz 1Kw
Protran 44-80303 44-80303 1
T4 Txfr Auto 12,5:50 Ohm 1,6-
30MHz 1kW
Protran 44-80301 44-80301 1
08-06000-001 - Combiner 4 way PCB 1kW Amp
BOM Revision
Date Valid On
Page 1 of 1
