08-05985-001
03 -- Production
28.09.2006
Ref Descri
tion Manufacturer Manufacturer's P/N Codan P/N Qt
ALC PTT Switch PCB 08-05985 1
ALC PTT Switch 04-03422 1
1 PCB, ALC PTT Switch IMP 07-01991-01 07-01991-01 1
2 Stake, Terminal Autosplice 7-22461-5 61-40300-004 3
C1 Not Assigned Codan **-00000-004 99-00000-004 1
C2 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C3 SOT 5% 50V NPO 0805
NiSn
Philips 0805CG 46-00000-081 1
C4 150p 5% 50V NPO 0805
NiSn
Philips 0805CG151J9BB- 46-21500-081 1
C5 5,5-65p 250V Foil Trim Cap Philips 2222 808 32659 49-30103 1
C6 47p 5% 50V NPO 0805
NiSn
Philips 0805CG470J9B200 46-14700-080 1
C7 56p 5% 50V NPO 0805
NiSn
Philips 0805CG560J9B200 46-15600-081 1
C8 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C9 Not Assigned Codan **-00000-004 99-00000-004 1
C10 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C11 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C12 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C13 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
D1 Diode, Schottky 70V 70mA
SOT23
Siemens BAS70 BAS70 1
D2 Diode, Schottky 70V 70mA
SOT23
Siemens BAS70 BAS70 1
D3 Diode, Schottky 70V 70mA
SOT23
Siemens BAS70 BAS70 1
D4 Diode, Schottky SOT23 Philips BAT54 BAT54 1
D5 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
J1 Socket, Coax Mini Vertical
Fixed
Taiko Denki TMP-J01X-V6 60-19390-001 1
J2 Socket, Coax Mini Vertical
Fixed
Taiko Denki TMP-J01X-V6 60-19390-001 1
K1 Relay, 2C Bif 12V 720
Ohm
Matsushita DS2Y-S-DC12 64-21223-272 1
K2 Relay, Vert 1C 12V 8A 306
Ohm
Siemens V23057-B0002-A101 64-31120-232 1
L1 Ind, 1mH 10% 1812 Coilcraft 1812LS-105XKBC 43-83100-000 1
L2 Ind, 1mH 10% 1812 Coilcraft 1812LS-105XKBC 43-83100-000 1
P1 Header (P) 10way 2row Boxed
Fix
I-Technos HDM410S02 60-00100-003 1
R1 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R2 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R3 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R4 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
08-05985-001 - ALC PTT Switch PCB 500W
BOM Revision
Date Valid On
Page 1 of 2
