Codan NGT 2012 RF User Manual

08-05889-001
18 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Filter, 45- MHz 4Pole 15 kHz
BW
KDK 45M15B 65-91115-000 2
Build Standard, 2010 01-01252 1
RF/IF PCB 08-05889 1
RF/IF 04-03378 1
TP, NGT RF/IF PCB 10-00899 1
1 PCB, IF/RF 07-01961-07 07-01961-07 1
2 Screen, VCO1 & Mixer Metalcraft 05-06518 05-06518 1
3 Screen, VCO Metalcraft 05-07079 05-07079 1
4 Screen, DDS Metalcraft 05-07080 05-07080 1
5 Insulator, Oven RMAX 06-02045 06-02045 1
6 Jumper (S) 2way Open Top Molex 15-38-1024 60-90410-001 1
7 Label, Serial/Barcode Codan 06-02068 06-02068 1
8 Crystal Oven Assembly Codan 08-05963-001 08-05963-001 1
9 Cable, Ribbon, Audio - RF Auto Assemblies 08-05489-001 08-05489-001 1
10 Cable, Rx coax Auto Assemblies 08-05491-001 08-05491-001 1
11 Cable, Tx coax Auto Assemblies 08-05492-001 08-05492-001 1
C101 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C102 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C103 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C104 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C105 820p 5% 50V NPO 0805
NiSn
Philips 0805CG821J9B200 46-28200-081 1
C106 820p 5% 50V NPO 0805
NiSn
Philips 0805CG821J9B200 46-28200-081 1
C107 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C108 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C109 820p 5% 50V NPO 0805
NiSn
Philips 0805CG821J9B200 46-28200-081 1
C110 820p 5% 50V NPO 0805
NiSn
Philips 0805CG821J9B200 46-28200-081 1
C111 10n 10% 100V X7R 0805
NiSn
Philips 08052R103K0B200 46-41000-281 1
C112 150p 5% 50V NPO 0805
NiSn
Philips 0805CG151J9BB- 46-21500-081 1
C113 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C114 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C115 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C116 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C117 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C118 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C119 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C120 22p 5% 50V NPO 0805
NiSn
Philips 0805CG220J9B200 46-12200-081 1
08-05889-001 - RF/IF PCB
BOM Revision
Date Valid On
Page 1 of 21
