Codan NGT 2012 RF User Manual

08-05997-001
01 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Splitter 2 way 500W Amp 04-03419 1
* Splitter 2 way PCB 500W Amp 08-05997 1
1 PCB, Splitter 2 way 500W Amp Codan 07-01996-02 07-01996-02 1
2 Standoff, PCB 3,6x6 PEM KFE-3,6-6ET 33-53604-060 4
C1 39p 2% 100V NPO CE
Cap
Philips 2222 680 10399 46-13900-011 1
J1 Socket, Coax Mini Vertical
Fixed
Taiko Denki TMP-J01X-V6 60-19390-001 1
J2 Socket, Coax Mini Vertical
Fixed
Taiko Denki TMP-J01X-V6 60-19390-001 1
J3 Socket, Coax Mini Vertical
Fixed
Taiko Denki TMP-J01X-V6 60-19390-001 1
R4 200 Ohm 5% 0,33W CF
Res
Philips 2322 211 13201 40-22000-020 1
R5 200 Ohm 5% 0,33W CF
Res
Philips 2322 211 13201 40-22000-020 1
T1 Txfr Auto 50:25 Ohm 1,6-
30MHz 10W
Protran 44-80296 44-80296 1
T2 Txfr Input Splitter 2 way 1,6-
30MHz
Protran 44-80298 44-80298 1
08-05997-001 - Splitter 2 way PCB 500W Amp
BOM Revision
Date Valid On
Page 1 of 1
