Codan NGT 2012 RF User Manual

08-05628-001
14 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Opt SR Codan 15-10489 15-10489 0.01
Customising Reference
Booklet
11-90350 1
Build Standard, 2010 01-01252 1
* RF Unit, NGT 08-05628 1
* RF Unit, NGT 08-05628 1
1 Chassis Diemetrics 05-07057 05-07057 1
2 Cover & Gasket Assembly Diemetrics 08-06150-001 08-06150-001 2
3 Screen, Audio I/F Metalcraft 05-07102 05-07102 1
4 Screen, Application Processor Metalcraft 05-07103 05-07103 1
5 Screen, Rx/Exciter Metalcraft 05-07104 05-07104 1
6 Card, Voltage Warning Aust Printing 06-00380 06-00380 1
8 Label, Serial/Barcode Codan 06-02068 06-02068 1
12 PA c/w Heatsink PCB Codan 08-06461-001 08-06461-001 1
13 RF/IF PCB Codan 08-05889-001 08-05889-001 1
14 Filter & Control PCB Codan 08-05910-001 08-05910-001 1
15 Screw, M3x8 TAPTITE 2
P/Pozi
Ajax Fasteners 31-03008-580 31-03008-580 26
16 Screw, M3x8 TAPTITE 2 Csk
Pozi
Ajax Fasteners 304SS Bk to 01-00205 31-03008-782 4
17 Screw, M3x10 TAPTITE 2
P/Pozi
Ajax Fasteners 31-03010-582 31-03010-582 14
18 Washer, M3 304 SS Spring W.J.Smith 31-23001-580 31-23001-580 8
26 Label, WEEE 10x20mm
Black
Entech 06-02352-005 06-02352-005 1
101 Escutcheon, 2010 RF-Unit SR Entech 06-01929-001 06-01929-001 1
102 Label, Serial No. 2010 x 06-01959 06-01959 1
103 Application Processor PCB Codan 08-05265-001 08-05265-001 1
104 Audio I/F PCB Codan 08-05266-001 08-05266-001 1
105 Cable, CIB Intertech 08-05483-001 08-05483-001 1
106 Grommet, Blanking,NGT
Heatsink
Electronic Synergies 06-02294 06-02294 1
08-05628-001 - RF Unit, NGT SR
BOM Revision
Date Valid On
Page 1 of 1

Codan NGT 2012 RF Specifications

General

Brand	Codan
Model	NGT 2012 RF
Category	Transceiver
Language	English
