Codan NGT 2012 RF User Manual

08-05416-001
11 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
X3 PA Assembly Proc (Interim) 11-06034 1
TP, NGT PA Alignment 10-00816 1
PA & Filter 04-03169 1
Build Standard, 2010 01-01252 1
Filter & Control PCB 08-05416 1
1 PCB, Filter & Control Codan 07-01800-07 07-01800-07 1
2 Label, Serial/Barcode Codan 06-02068 06-02068 1
3 Cable, Coax Intertech 08-05484-001 08-05484-001 1
5 Cable, Ribbon, PA - Filter Auto Assemblies 08-05487-001 08-05487-001 1
6 Cable, Ribbon, Filter - Audio Auto Assemblies 08-05488-001 08-05488-001 1
B1 Temp Sensor 10mV/degree C
SOT23
National Semiconduct LM50CIM3X LM50CIM3X 1
C1 3,3n 10% 100V X7R 1206
NiSn
Philips 12062R332K0BB- 46-33300-280 1
C2 120p 5% 500V NPO 1210
NiSn
Philips 1210CG121GBB- 46-21200-082 1
C3 120p 5% 500V NPO 1210
NiSn
Philips 1210CG121GBB- 46-21200-082 1
C4 39p 5% 500V NPO 1206
NiSn
Philips 1206CG390GBB- 46-13900-082 1
C5 120p 5% 500V NPO 1210
NiSn
Philips 1210CG121GBB- 46-21200-082 1
C6 120p 5% 500V NPO 1210
NiSn
Philips 1210CG121GBB- 46-21200-082 1
C7 120p 5% 500V NPO 1210
NiSn
Philips 1210CG121GBB- 46-21200-082 1
C8 330p 5% 500V NPO 1210
NiSn
Philips 1210CG311GBB- 46-23300-082 1
C9 220p 5% 500V NPO 1210
NiSn
Philips 1210CG221GBB- 46-22200-082 1
C10 150p 5% 500V NPO 1210
NiSn
Philips 1210CG151GBB- 46-21500-082 1
C11 470p 5% 500V NPO 1210
NiSn
Philips 1210CG471GBB- 46-24700-082 1
C12 470p 5% 500V NPO 1210
NiSn
Philips 1210CG471GBB- 46-24700-082 1
C13 390p 5% 500V NPO 1210
NiSn
Philips 1210CG391GBB- 46-23900-082 1
C14 330p 5% 500V NPO 1210
NiSn
Philips 1210CG311GBB- 46-23300-082 1
C15 330p 5% 500V NPO 1210
NiSn
Philips 1210CG311GBB- 46-23300-082 1
C16 330p 5% 500V NPO 1210
NiSn
Philips 1210CG311GBB- 46-23300-082 1
C17 470p 5% 500V NPO 1210
NiSn
Philips 1210CG471GBB- 46-24700-082 1
C18 470p 5% 500V NPO 1210
NiSn
Philips 1210CG471GBB- 46-24700-082 1
C19 390p 5% 500V NPO 1210
NiSn
Philips 1210CG391GBB- 46-23900-082 1
C20 220p 5% 500V NPO 1210
NiSn
Philips 1210CG221GBB- 46-22200-082 1
C21 180p 5% 500V NPO 1210
NiSn
Philips 1210CG181GBB- 46-21800-082 1
C22 470p 5% 500V NPO 1210
NiSn
Philips 1210CG471GBB- 46-24700-082 1
08-05416-001 - Filter & Control PCB
BOM Revision
Date Valid On
Page 1 of 11
