Codan NGT 2012 RF User Manual

08-03817
02 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
* Line Isolation Unit PCB Rapier Electronics 08-03817 08-03817 1
1 PCB, Line Isolation Unit Codan 07-01257 07-01257 1
2 Stake, Terminal Autosplice 7-22461-5 61-40300-004 2
F1 Fuse, STD Wire-end
100mA
Schurter 034.1906 63-00010-010 1
J1 Socket, 6way 4Cct Modular
PCB 90
Molex 90077-0046 60-00063-102 1
R1 22 Ohm 5% 2,5W MF
Res
Philips 2322 192 32209 40-12200-605 1
T1 Txfr, Line isolating Ericsson REKP4999030 43-30105-001 1
V1 Diode, Zener 5,1V 5% 5W Motorola 1N5338B 1N5338B 1
V2 Diode, Zener 5,1V 5% 5W Motorola 1N5338B 1N5338B 1
08-03817 - Line Isolation Unit PCB
BOM Revision
Date Valid On
Page 1 of 1
