Codan NGT 2012 RF User Manual

08-05998-001
01 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Combiner 2 way 500W Amp 04-03428 1
* Combiner 2 way PCB 500W
Amp
08-05998 1
1 PCB, Combiner 2 way 500W
Amp
IMP 07-01997-03 07-01997-03 1
2 Standoff, PCB 3,6x4 PEM KFE-3,6-4ET 33-53604-040 1
3 Standoff, PCB 3,6x6 PEM KFE-3,6-6ET 33-53604-060 2
4 Stake, Terminal Autosplice 7-22461-5 61-40300-004 6
C1 3,3n 10% 100V CE Cap Philips 2222 630 03332 46-33300-200 1
C2 39p 5% 500V NPO CE
Cap
Murata DD07 CH 390J 500 46-13900-020 1
D1 Diode, Schottky HV HP 5082-2800 5082-2800 1
J1 Socket, MCX Straight
PCB
Chin Nan 27-05-TGN 60-19300 1
J2 Socket, MCX Straight
PCB
Chin Nan 27-05-TGN 60-19300 1
R2 470 Ohm 5% 0,33W CF
Res
Philips 2322 211 13471 40-24700-020 1
T1 Txfr Output Combine 2 way 1,6
-
30MHz 500W
Protran 44-80299 44-80299 1
T2 Txfr Auto 25:50 Ohm 1,6-
30MHz 500W
Protran 44-80297 44-80297 1
08-05998-001 - Combiner 2 way PCB 500W Amp
BOM Revision
Date Valid On
Page 1 of 1
