Codan NGT 2012 RF User Manual

03 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05977-001 - 500W HF Amp PCB
BOM Revision
Date Valid On
R18 47 Ohm 5% 0,33W CF
Res
Philips 2322 211 13479 40-14700-020 1
R19 1k Ohm 5% 0,33W CF
Res
Philips 2322 211 13102 40-31000-020 1
R20 10 Ohm 5% 0,33W CF
Res
Philips 2322 211 13109 40-11000-020 1
R21 33 Ohm 5% 0,33W CF
Res
Philips 2322 211 13339 40-13300-020 1
R22 1k Ohm 5% 0,33W CF
Res
Philips 2322 211 13102 40-31000-020 1
R23 1k Ohm 5% 0,33W CF
Res
Philips 2322 211 13102 40-31000-020 1
R24 1k Ohm 5% 0,33W CF
Res
Philips 2322 211 13102 40-31000-020 1
R25 470 Ohm 5% 0,33W CF
Res
Philips 2322 211 13471 40-24700-020 1
R26 1k Ohm 5% 0,33W CF
Res
Philips 2322 211 13102 40-31000-020 1
R101 180 Ohm 5% 3,0W MF
Res
BC Components 2322 195 14181 40-21800-690 1
R102 180 Ohm 5% 3,0W MF
Res
BC Components 2322 195 14181 40-21800-690 1
R103 180 Ohm 5% 3,0W MF
Res
BC Components 2322 195 14181 40-21800-690 1
R104 180 Ohm 5% 3,0W MF
Res
BC Components 2322 195 14181 40-21800-690 1
R105 180 Ohm 5% 3,0W MF
Res
BC Components 2322 195 14181 40-21800-690 1
R106 200 Ohm 5% 2,0W MF
Res
BC Components 2306 198 53201 40-22000-691 1
R107 470 Ohm 5% 3,0W MF
Res
BC Components 2322 195 14471 40-24700-690 1
R110 470 Ohm 5% 3,0W MF
Res
BC Components 2322 195 14471 40-24700-690 1
R111 100k Ohm 1% 0,4W MF
Res
Philips 2322 156 11004 40-51000-501 1
R112 10,0k Ohm 1% 0,4W MF
Res
Philips 2322 156 11003 40-41000-501 1
R113 470 Ohm 5% 0,33W CF
Res
Philips 2322 211 13471 40-24700-020 1
V3 Transistor, NPN Si Philips BC550C BC550C 1
V4 Transistor, PNP Si Philips BC558 BC558 1
V6 MOSFET, Power N Channel Motorola MTD3055EL1 MTD3055EL1 1
Page 4 of 4
