03 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05977-001 - 500W HF Amp PCB
BOM Revision
Date Valid On
D2 Diode, Schottky HV HP 5082-2800 5082-2800 1
D3 Diode, Zener 30V 5% 0,4W Philips BZX79-C30 BZX79C30 1
D4 Diode, Si fast low cap high
cond
Codan 23-10001 23-10001 1
D101 Diode, Schottky HV HP 5082-2800 5082-2800 1
D102 Diode, Schottky HV HP 5082-2800 5082-2800 1
D103 Diode, Zener 30V 5% 0,4W Philips BZX79-C30 BZX79C30 1
D104 Diode, Si fast low cap high
cond
Codan 23-10001 23-10001 1
J1 Socket, Coax Mini Vertical
Fixed
Taiko Denki TMP-J01X-V6 60-19390-001 1
J101 Socket, Coax Mini Vertical
Fixed
Taiko Denki TMP-J01X-V6 60-19390-001 1
L1 Inductor (Amp in) Lencom 44-70534 44-70534 1
L2 Inductor (Shunt in) Lencom 44-70535 44-70535 1
L3 Ind, 1,8uH 10% Epcos B78108-T1182-K9 43-80180-002 1
L4 Inductor, DC Feed Lencom 44-70536 44-70536 1
L5 Inductor, DC Feed Lencom 44-70536 44-70536 1
L6 Choke, EMI/EMC 0A DC
>1MHz
Taiyo Yuden FBR07 HA 121 NB-00 43-90002 1
L101 Inductor (Amp in) Lencom 44-70534 44-70534 1
L102 Inductor (Shunt in) Lencom 44-70535 44-70535 1
L103 Ind, 1,8uH 10% Epcos B78108-T1182-K9 43-80180-002 1
L104 Inductor, DC Feed Lencom 44-70536 44-70536 1
L105 Inductor, DC Feed Lencom 44-70536 44-70536 1
L106 Choke, EMI/EMC 0A DC
>1MHz
Taiyo Yuden FBR07 HA 121 NB-00 43-90002 1
P1 Header (P) 10way 2row Boxed
Fix
I-Technos HDM410S02 60-00100-003 1
R1 180 Ohm 5% 3,0W MF
Res
BC Components 2322 195 14181 40-21800-690 1
R2 180 Ohm 5% 3,0W MF
Res
BC Components 2322 195 14181 40-21800-690 1
R3 180 Ohm 5% 3,0W MF
Res
BC Components 2322 195 14181 40-21800-690 1
R4 180 Ohm 5% 3,0W MF
Res
BC Components 2322 195 14181 40-21800-690 1
R5 180 Ohm 5% 3,0W MF
Res
BC Components 2322 195 14181 40-21800-690 1
R6 200 Ohm 5% 2,0W MF
Res
BC Components 2306 198 53201 40-22000-691 1
R7 470 Ohm 5% 3,0W MF
Res
BC Components 2322 195 14471 40-24700-690 1
R10 470 Ohm 5% 3,0W MF
Res
BC Components 2322 195 14471 40-24700-690 1
R11 100k Ohm 1% 0,4W MF
Res
Philips 2322 156 11004 40-51000-501 1
R12 10,0k Ohm 1% 0,4W MF
Res
Philips 2322 156 11003 40-41000-501 1
R13 470 Ohm 5% 0,33W CF
Res
Philips 2322 211 13471 40-24700-020 1
R14 Not Assigned Codan **-00000-004 99-00000-004 1
R15 Pot,1k Lin MG Trim Noble VTP 42-31076-000 1
R16 470 Ohm 5% 0,33W CF
Res
Philips 2322 211 13471 40-24700-020 1
R17 3,9k Ohm 5% 0,33W CF
Res
Philips 2322 211 13392 40-33900-020 1
Page 3 of 4
