08-05514-001
06 -- Production
27.09.2006
Ref Descri
tion Manufacturer Manufacturer's P/N Codan P/N Qt
Build Standard, 2030 01-01250 1
* Tcvr Junction Box 08-05514 1
1 Junction Box Diemetrics 05-07066 05-07066 1
2 Junction Box, Base Plate Diemetrics 05-07067 05-07067 1
3 Label, Serial/Barcode Codan 06-02068 06-02068 1
4 MicroP PCB Codan 08-05317-001 08-05317-001 1
5 Audio PCB Codan 08-05986-001 08-05986-001 1
6 Loom, CIB Auto Assemblies 08-05517-001 08-05517-001 2
7 Loom, Handset Auto Assemblies 08-05518-001 08-05518-001 1
8 Loom, Serial Auto Assemblies 08-05519-001 08-05519-001 1
9 Loom, GPIO Auto Assemblies 08-05520-001 08-05520-001 1
10 Speaker Filter PCB Codan 08-05724-001 08-05724-001 1
11 Bush, Transistor TO-220 Motorola B51547F019 30-03801-001 1
12 Washer, Mica (1kV) TO-220 Philips 56359B 30-45002-002 1
13 Screw, M3x6 TAPTITE 2
P/Pozi
Ajax Fasteners 304 Stainless 31-03006-580 8
17 Washer, Insulating Stepped Micro Plastics 12SWS1014 Black 32-90000-002 1
18 Screw lock assy, 'D' 5,0mm
Stud
ACD 1-024 60-91563-001 4
19 Screw, M3x8 TAPTITE 2
P/Pozi
Ajax Fasteners 31-03008-580 31-03008-580 1
20 Heat, Transfer Compound Gensil GENSIL 13 45gm Tube 71-31000-004 0.01
08-05514-001 - Junction Box Assy
BOM Revision
Date Valid On
Page 1 of 1
To Next Page
