Codan NGT 2012 RF User Manual

08-05870-001
01 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
NRI Vocoder 04-03370 1
NRI Vocoder PCB 08-05870 1
1 PCB, NRI Vocoder Morris Productions 07-01949-02 07-01949-02 1
C1 220p 5% 50V NPO 0805
NiSn
Philips 0805CG221J9BB 46-22200-081 1
C2 220p 5% 50V NPO 0805
NiSn
Philips 0805CG221J9BB 46-22200-081 1
C3 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C4 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C5 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C6 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C7 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C8 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C9 33u 20% 16V 7343 TA
Cap
AVX TAJD336M016R 47-13301-600 1
C10 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C11 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C12 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C13 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C14 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C15 10p 5% 50V NPO 0805
NiSn
Philips 0805CG100J9B200 46-11000-081 1
C16 10p 5% 50V NPO 0805
NiSn
Philips 0805CG100J9B200 46-11000-081 1
C17 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C18 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C19 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C20 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C21 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C22 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C23 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C24 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
IC1 Amp, Op Dual Fast
SOIC8
Texas Instruments TLE2082CD XA-02082-700 1
IC2 Codec, 8-bit Mu-Law Serial I/F
SOIC16
Texas Instruments TP3054BDW YN-03054-700 1
IC3 300v, Voltage, Switching
SOIC8
Linear Tech LT1054CS8 XB-01054-700 1
08-05870-001 - NRI Vocoder PCB
BOM Revision
Date Valid On
Page 1 of 3
