Codan NGT 2012 RF User Manual

05 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05855-001 - User Connect PCB, 3030
BOM Revision
Date Valid On
R133 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R134 100 Ohm 5% 0,06W 0603 Philips 2322 702 60101 40-21000-121 1
R135 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R136 2,2k Ohm 5% 0,06W 0603 Philips 2322 702 60222 40-32200-121 1
R137 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R138 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R139 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R140 100k Ohm 5% 0,06W 0603 Philips 2322 702 60104 40-51000-121 1
V101 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V102 Transistor, PNP Si SOT23 Philips BC856 BC856 1
V103 Diode, Zener 15V 5% 0,2W
SOT23
Philips BZX84-C15 BZX84C15 1
V104 Transistor, PNP Si SOT23 Philips BC856 BC856 1
V105 Transistor, PNP Si SOT23 Philips BC858 BC858 1
V106 Transistor, NPN Si SOT23 Philips BC848 BC848 1
Page 5 of 5
