Codan NGT 2012 RF User Manual

08-06067-001
01 -- Production
25.10.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Power Supply 3061/3062 04-03453 1
Final Assy 500W PSU 11-06103 1
TP, 500W/1kW PSU Final Assy 10-00937 1
* Final Assy, 500W PSU 08-06067 1
1 Cover, Cable PSU HPPA Codan 05-07338 05-07338 1
2 Panel, Base/Top, HPPA/PSU Metalcraft 05-07347 05-07347 1
3 Label, Rating 500W PSU Codan 06-02149-001 06-02149-001 1
4 Label, Chassis Earth Entech 06-02162 06-02162 1
5 Structural Assy, 500W PSU Codan 08-06066-001 08-06066-001 1
6 Cable, DC Filter to O/P Auto Assemblies 08-06107-001 08-06107-001 1
7 Cable, AC I/P to Switch 3061 Auto Assemblies 08-06108-001 08-06108-001 1
8 Cable, DC (-) Filter to Earth Auto Assemblies 08-06110-001 08-06110-001 1
9 Cable, SMPS Earth to Chassis Auto Assemblies 08-06111-001 08-06111-001 1
10 Cable, DC (+) SMPS to Filters Auto Assemblies 08-06112-001 08-06112-001 1
11 Cable, DC (-) SMPS to Filters Auto Assemblies 08-06113-001 08-06113-001 1
12 Cable, Switch to SMPS Active Auto Assemblies 08-06114-001 08-06114-001 1
13 Cable, Switch to SMPS Neutral Auto Assemblies 08-06115-001 08-06115-001 1
14 Clamp, Cable Adhesive Richco SK3 30-05102-001 1
15 Clamp, Cable Adhesive Richco SK6 30-05102-002 3
16 Bush, Strain Relief Heyco 1170 (BLACK) 30-03802-006 1
17 Label, Danger isolated mains Farnell 143-548 30-23001-003 1
18 Tie, Cable 2,5mm W x 115mm
Long
Richco WIT 18 R 30-39100-004 3
19 Screw, M3x6 304 SS Pan Pozi * 31-23006-580 31-23006-580 16
20 Screw, M3x8 304 SS Pan Pozi * 31-23008-580 31-23008-580 8
21 Screw,M3x10 304 SS Bk Csk
Pozi
Spec 01-00205 31-23010-782 31-23010-782 2
22 Nut, M3 304 SS Nyloc James Glen 31-23000-780 31-23000-780 4
23 Washer, M4 304 SS Normal * 31-24001-080 31-24001-080 4
24 Plug, 3way 250VAC 10A Free Bulgin PX0580/63 60-80030-000 1
25 Switch, Rocker DPST
Illuminated 250V 16A
Arcolectric C1353VQNAC 62-02103 1
26 Filter, RFI 250VAC 20A Spade
Connector
Schaffner FN2020-20-06 78-06030 2
27 PSU, 90-264VAC in, 48-
72VDCout750W SMPS
Amtex ZX750-9660-CT 78-16021 1
28 Cable, Filter to Switch Active Auto Assemblies 08-06218-001 08-06218-001 1
29 Cable, Filter to Switch Neutral Auto Assemblies 08-06219-001 08-06219-001 1
30 Label, WEEE 10x15mm
Black
Entech 06-02352-004 06-02352-004 1
08-06067-001 - 3061 Power Supply 500W
BOM Revision
Date Valid On
Page 1 of 1
