Codan NGT 2012 RF User Manual

08-05986-001
05 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Audio PCB 08-05986 1
Audio, Junction Box 04-03423 1
Spec, Audio (JB) PCB Board
Level
01-01051 1
NGT JBox Audio PCB 11-06093 1
1 PCB, Audio Codan 07-01992-02 07-01992-02 1
2 Label, Serial/Barcode Codan 06-02068 06-02068 1
3 Jumper (S) 2way Open Top Molex 15-38-1024 60-90410-001 2
C1 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C2 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C3 3,3n 10% 100V X7R 0603
NiSn
Vishay VJ0603Y332KXBAC 46-33300-282 1
C4 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C5 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C6 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C7 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C8 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C9 Not Fitted Codan **-00000-001 99-00000-001 1
C10 1000u 16V Ax EL Cap Jamicon SKR102T1CJ21 48-31001-651 1
C11 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C12 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C15 100u 25V 105'C SMD EL
Cap Low ESR
Nippon Chemicn MVY25VC100MF80 48-21002-502 1
C16 470u 16V Ax EL Cap Jamicon SKR470T1CG18 48-24701-651 1
C17 2,2n 5% 50V NPO 1206
NiSn
Philips 1206CG222J9BB- 46-32200-081 1
C18 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C19 2,2n 5% 50V NPO 1206
NiSn
Philips 1206CG222J9BB- 46-32200-081 1
C20 3,9n 5% 50V NPO 1206
NiSn
Philips 1206CG392J9BB0C 46-33900-080 1
C21 330p 5% 50V NPO 0603
NiSn
Phycomp 0603CG331J9B200 46-23300-083 1
C22 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C23 4,7n 5% 25V NPO 0805
NiSn
Phycomp 0805CG472J8BB00 46-34700-081 1
C24 4,7n 5% 25V NPO 0805
NiSn
Phycomp 0805CG472J8BB00 46-34700-081 1
C25 220p 5% 50V NPO 0603
NiSn
Philips 0603CG221C9BB00 46-22200-083 1
C26 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C27 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
08-05986-001 - Audio PCB
BOM Revision
Date Valid On
Page 1 of 8
